Grain Fan Assist Twin

‘The Successor to CropCool?’

Especially for farmers who would like to switch on their Wall Fans (we supply Hydor Fans) at the same time as their Pedestal Fans. (This is ideal if you have been having condensation problems inside your Grainstore?)

Grain Fan Assist Twin (like CropCool) can operate up to 2 single Ph. Fans off a 13amp/16amp socket, (also available mounted on a VBW8 Fan – ie dedicated to run 1 fan only, see below)

It has a 2M Wireless Grain Temperature probe which can also communicate with Extraction Fan Assist (if installed)

Your Wall Fans can be wired into Extraction Fan Assist (single or 3-ph) so they are switched on at the same time as the Pedestal Fans. (This helps maximise Grain Cooling & Removal of Condensation - such as drips from the roof onto your crop or around your Pedestals)

Grain Fan Assist Twin (1ph)

Will run 2 x 1.1kw fans only when air temperature is lower than the grain temperature by pre-set amount.
Avoids unnecessary fan running times.
Will require 2 metre Crop Temperature Probe as detailed below.
Inbuilt fan running time clock.
Grain Fan Assist Twin arrives ready to use and requires limited installation.

Grain Fan Assist Twin (3ph)

As above but with 2 x 16 amp 4 pin 3ph sockets. Includes starters and overloads for 1.1kw fans. Can be adapted to run 2.2kw fans if required.

Grain Fan Assist Wireless – 2m Crop Temperature Probe

Multiple units can operate from one Grain Fan Assist Wireless Crop Temperature Probe. Probe will monitor Crop Temperature, Ambient Temperature and Ambient relative humidity (rh). This probe can be used with GFAW, GFAW Twin and Multi Fan Hub.
